1000KG Wheel Loader
HZM810 Mini Wheel Loader Advantage
Hydrostatic System
It enables seamless, accurate and agile operation, fully catering to the demands of the European market.
Multifunctional Joystick
Delivers simple, responsive and user-friendly manipulation to greatly boost operator comfort.
Kubota Stage V Engine
Generates robust power output while lowering fuel consumption. Its environmentally friendly performance fully satisfies prevailing emission regulations.
Compact Structure
Perfectly adapted to farms, gardens and urban construction sites with restricted working space.
Wide Application Flexibility
Compatible with diverse attachments, allowing the machine to accomplish various tasks efficiently and effortlessly.
HZM810 Mini Loader Product Introduction
This compact wheel loader is equipped with an imported Kubota engine alongside an Italian PWG hydrostatic system, delivering smooth, accurate and extremely responsive operation. The multifunctional electric joystick enables easy handling, allowing operators to carry out every task with superior precision and comfort.
The machine generates strong power while maintaining low noise and excellent fuel efficiency. It meets environmental requirements and lowers day-to-day running expenses. Designed for intuitive operation and broad versatility, it is compatible with various attachments such as buckets, pallet forks, road sweepers and snow blades, capable of smoothly executing construction, landscaping, farming and material handling tasks.
Despite its compact frame, the loader offers formidable power. It maintains a perfect equilibrium of performance, comfort and efficiency, making it an ideal choice for contemporary job sites and professional operators seeking reliable equipment and maximum productivity.
Product Details
|
|
Kubato engine, strong power | Electric joystick,control various functions |
|
|
EURO Quick hitch easy quick-change attachments | Rear wiper meet European standard |
Product Specifications
Engine | |
(1) Model: | Kubota V1505 |
(2) Rated Power: | 18.2(KW) |
(3) Rated Speed: | 2300(rpm) |
(4) Number of cylinder | 4 |
Driving system | |
(1) Type of driving | Hydr0static |
(2) Drive | Oil engine |
(3) Axle | K80b |
(4)Travel speed (option) | 0-11(14)/9(17)km/h |
Operating Specifications | |
(1) Bucket Capacity : | 0.4(m³) |
(2) Loading Capacity: | 1000(KG) |
(3) Operation Weight: | 2560(KG) |
Hydraulic system | |
(1)Working hydraulics discharge volume(max)(0pition)L/min | 41.4(50.4)/32-64(39-78) |
(2)Drive hydraulic working pressure (max)option | 310 bar |
(3)Work hydraulic working pressure (max)option | 180 bar |
Overall Dimensions | |
(1) Overall Length: | 4067(MM) |
(2) Overall Height: | 2254(MM) |
(3) Overall Width: | 1451(MM) |
(4) Dumping Height: | 1985(MM) |
(5) Dumping Reach: | 603(MM) |
(6) Min.Ground Clearance: | 351(MM) |
(7) Wheel Base: | 1595(MM) |
(4) Lifting Time: | 8s |
(6)Min.Turning Radius，bucket carry | 3375(MM) |
(7)Max.Turning Angle,outside of tire | 38° |
Brake System | |
(1) Service Brake: | Inch brake |
Tyre | 31×15.5-15 |
